| parameters |
| System |
SoC: Allwinner H313 |
| CPU: Quad-core ARM Cor texA53 |
| GPU: Mali-G31 |
| DRAM: DDR3 2GB |
| FLASH: EMMC 16GB |
| OS: Android Q(11.0) |
| Network |
RJ45 Interface 10M/100M adaptive |
| Build in Wi-Fi 2.4GHz+5GHz |
| I/O |
| Video Output |
HD2.0(4K60), AV |
| Network |
RJ45, Buildin Wi-Fi antenna |
| Peripheral Interface |
USB2.0x2 |
| Power Interface |
DC 5V 2A |
| Other Interface |
IR receiver, LED indicato |
| Media |
| Video |
Decoder: |
| • H.265 Main10 L5.1 decoder up to 4K 60fps |
| • VP9 Profile 2 decoder up to 4K 30fps |
| • AVS2 JiZhun 10bit decoder up to 4K 30fps |
| • H.264 BP/MP/HP L4.2 decoder up to 4K 30fps |
| • Multi-format 1080p 60fps video playback formats, including H.264 BP/MP/HP, H.263 BP, VP8, MPEG-1 MP/HL, MPEG-2 MP/HL, MPEG-4 |
| SP/ASP L5, AVS+/AVS JiZhun, WMV9/VC1, etc |
| Format: |
| MKV, TS, M2TS, MOV, MP4, RM, RMVB, AVI, MPG, MPEG, DAT, VOB, FLV etc. |
| Audio |
Decoder: |
| MPEG 1/2/2.5, Audio Layer 1/2/3, WMA Version 4/4.1/7/8/9, WMA Pro, LPCM, PCM, Vorbis, Flac, ALAC, APE, AAC-LC/HEAAC/HE-AAC v2, |
| Real Audio, AC-3/DD+/AC-4, MPEG-H |
| Format: |
| MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, ALAC, MPEG, MP1, MP2, MPA etc. |
| Subtitle Format |
SMI, SRT, SSA, ASS,SUB, SUB+IDX, ISO Navigation |
| Photo Format |
HD JPEG/BMP/GIF/PNG/TIFF |
| Features |
| Network Streaming |
HTML5, RTSP, HLS, Smooth streaming |
| Multi-screen interactive |
Miracast, DLNA and Airplay |
| Local Media Playback |
Video/Audio/Picture |
| TV APP |
Google Play(TV version), Google Voice Assistant, YouTube(4K), (TV Version), |
| Disney+(TV Version up to 720P), HBO Max(TV Version) Android TV APP |
| External Storage |
USB storage max to 2TB (FAT32/NTFS) |
| System Upgrading |
Upgrading via USB disk or internet |
| Other parameters |
| Input Voltage |
DC IN 5V/2A |
| Power Consumption |
8W Max |
| Operation Temperature |
0~40℃, Humidity<95% |
| Physical characteristics |
Size: 79*79*17MM |
| Weight: |
| Material |
| Proposed Accessory |
Power adapter, User manual, HD cable, BT Voice RCU |
